Refer to the Headrest System Wiring Diagram on Page 6. Be sure that. (Audiovox P/N FMDIRB) can be installed which will improve audio quality. 7) After verifying the proper operation of the system, mount each component.. headrest sYstem WiriNG diaGram Master Monitor Satellite Monitor OPTIONAL FM DIRECT CONNECTION. AVXMTGHR1M WIRING DIAGRAM Headrest Monitor 12V+VDC Ground Video In Yellow RED (P/N. PAGE 8 CONTROLS AND INDICATORS DIAGRAM (FRONT VIEW) POWER - MUTE SOURCE + VOLUME MENU VOLUME MUTE IR HEADPHONE TRANSMITTER LENS COVER IR SENSOR OPEN AUX IN HEADPHONE JACK REMOTE CONTROL OPERATION NOTE: The remote control has a battery installed with a pull tab.
Audiovox 5 inch navigation monitor 5.8 inch navigation monitor with 1 video input capability operation manual lcm5n, lcm58n (11 pages) Monitor AUDIOVOX MM1500 User Manual.. AVXMTGHR1D WIRING DIAGRAM Headrest Monitor Headrest Monitor GREEN (P/N.: 45-2S-08230G) (P/N 45-2Z-08200G Note: The headrests will still have the Red and Green DIN cables.. 3. Replace the headrest cover with the black or pewter cover and secure the headrest cover by re-attaching the velcro tabs. 4. Pull the monitor cables back out of the tubes while lowering the monitor into position. Hook the tabs at the top of the monitor into the top of the headrest and align the two holes in the monitor with the screw holes in.
