Before you start installing your new furnace, take the time to read these instal-lation and operating instructions. We have prepared them for your benefit to save time and provide some helpful knowledge on wood and coal burning. Save the instructions for future use. It won't take long for you to realize the benefit of solid fuel heating, however, maintenance is the key to a long lasting.. NOTE: The furnace is partially prewired all that is required is the wiring of the distribution fan (see wiring diagram, page 18) and the wiring to wall the thermostat.
